Characteristic

◆ Small footprint, no need to use compressed air; Fast changeover;

◆ Can transport flat square material, triangular or four corners and other special-shaped materials, as well as Φ2 or so small materials, cost-effective;

◆ Using pulse data control, the cutting end of the first piece of material can be stably controlled within 0.20mm;

◆ PLC plus servo, touch screen control, data operation, easy to use;

◆ Electrical and mechanical faults can be diagnosed by themselves, easy and fast maintenance;

◆ The tool life can be managed, the materials and production capacity can be counted, which is convenient for quality control and operation management.

ITEM	LSCT/N-08	LSCT/N-12	LSCT/N-16	LSCT/N-20
Bar diameter	φ 2~8 mm	φ 4~12 mm	φ 5~15 mm	φ 6~20 mm
Bar length	2500~3000 mm
Magazine	φ8*35pcs	φ12*23pcs	φ15*18pcs	φ20*14pcs
Net weight	About 165 kg	About 155 kg
Consumption	0.61 kw	0.46 kw
Power	1 Ph 200-240V AC 50-60H
